Product Summary
The IXFR44N50Q is a Power MOSFET. The applications are (1)DC-DC converters; (2)Battery chargers; (3)Switched-mode and resonant-mode power supplies; (4)DC choppers; (5)AC motor control.
Parametrics
IXFR44N50Q absolute maximum ratings: (1)VDSS: 500 V; (2)VDGR: 500 V; (3)VGS: ±20 V; (4)VGSM: ±30 V; (5)ID25:34 A; (6)ID: 176 A; (7)IAR: 44 A; (8)EAR: 60mJ; (9)EAS: 2.5 J; (10)dv/dt: 5 V/ns; (11)PD: 310 W; (12)TJ: -55 to +150℃; (13)TJM: 150℃; (14)Tstg: -55 to +150℃; (15)TL: 300℃; (16)VISOL: 2500 V~; (17)Weight: 5 g.
Features
IXFR44N50Q features: (1)Silicon chip on Direct-Copper-Bond substrate: High power dissipation; Isolated mounting surface; 2500V electrical isolation; (2)Low drain to tab capacitance(<30pF); (3)IXYS advanced low Qg process; (4)Rugged polysilicon gate cell structure; (5)Rated for Unclamped Inductive Load Switching (UIS); (6)Fast intrinsic diode.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 IXFR44N50Q |
Ixys |
MOSFET 34 Amps 500V 0.12 Rds |
Data Sheet |
Negotiable |
|
||||
|
IXFR44N50Q3 |
Ixys |
MOSFET Q3Class HiPerFET Pwr MOSFET 500V/25A |
Data Sheet |
Negotiable |
|
||||
